Specs:
Finely tuned tube preamp circuit powered by high voltage to the tube anode
ILA/ILH dual modes paired with high and low gain for the tube, offering four tube sound styles
Precision constant current source built with discrete components
Equipped with 12 Panasonic film capacitors for tube preamp coupling
Specially selected linear regulators optimized for the tube’s resonance frequency
CNC-machined metal dual-tube shielding and protective cover
Tube vibration-damping design: 8 high-damping silicone buffers used on both sides
Two independent high-power positive and negative power supplies
16 Nichicon 10x12.5mm audio-grade aluminum electrolytic capacitors for the power supply filtering in the discrete headphone amp circuit
Selectable ±13V and ±15V power supply voltage levels for the headphone amp
Six Panasonic 18650 low internal resistance battery cells
Internal resistance variance between cells is less than 0.5 milliohms
Discrete headphone amp circuits use 8 TO252 packaged power transistors
Discrete large transistor emitters use 24 pieces of 250mW 0.5% precision low-temperature drift alloy resistors
AB to A headphone amp mode offers 11 adjustable static current levels
Double-click the power button to switch between pure tube preamp mode and tube preamp + discrete headphone amp mode
potentiometer as the same grade in the LP6 7th Anniversary Edition, with a visual volume design
Balanced output power per channel: 6500mW @ 32Ω, 1200mW @ 300Ω
